Product Description

The Vaculine 765602W is a large 45° elbow fitting specifically engineered for central vacuum hose retraction systems. This fitting provides precise angle redirection for installation in tight spaces and wall cavities where standard 90° connections are impractical. The part number 765602W identifies this as a heavy-duty, large-diameter elbow suitable for primary and secondary hose runs in Hide-A-Hose and similar retractable hose systems.

Constructed from durable PVC composite materials, this elbow fitting is designed to handle typical central vacuum system pressures without leakage or deterioration. The large bore accommodates standard-diameter central vacuum hoses, ensuring minimal airflow restriction and efficient system performance. The 45° angle allows flexible routing along walls, around corners, and through installation cavities during both new construction and retrofit projects.

Compatible with major central vacuum system brands including BEAM, Intervac, Vacuflo, and Chameleon systems that utilize standard large-diameter hose connections. The fitting integrates seamlessly into Hide-A-Hose retractable hose installations and other modular central vacuum architectures commonly found in Utah homes and commercial properties.

Swiss Boy Vacuum is an authorized dealer and installer of central vacuum components for the Wasatch Front since 1963. Our expert technicians stock genuine Vaculine fittings and can advise on proper installation, compatibility verification, and system design. Contact us at 801-298-3656 for installation guidance or to order replacement and upgrade fittings for your central vacuum system.

Why Choose This Product?

• 45° angle design reduces installation footprint compared to dual 90° elbows
• Large-diameter bore minimizes suction loss in hose retraction systems
• Durable PVC construction withstands typical central vacuum system pressures
• Compatible with BEAM, Intervac, Vacuflo, and Chameleon retractable systems
• Essential component for Hide-A-Hose and similar wall-cavity installations
• Smooth interior finish prevents debris accumulation and maintains airflow

Specifications

• Brand: Vaculine
• Part Number: 765602W
• Type: Large 45° Elbow Fitting
• Material: PVC Composite
• Application: Hose Retraction Systems, Central Vacuum Installation
• Bore Size: Large Diameter

Compatibility

• BEAM central vacuum systems
• Intervac retractable hose systems
• Vacuflo central vacuum installations
• Chameleon hose retraction systems
• Hide-A-Hose retractable hose networks
• Standard large-bore central vacuum hose connections

Use Case

Contractors, builders, and homeowners installing or upgrading central vacuum systems need the Vaculine 765602W when routing hose lines at 45° angles through walls, around structural elements, or in confined spaces. This fitting is essential for Hide-A-Hose and similar retractable systems where hoses must be concealed within walls or cabinetry. It solves the challenge of directional hose routing without requiring multiple connections or adapters, preserving system efficiency and reducing installation time. Whether you're installing a new central vacuum system in a new home or retrofitting an existing property, this elbow fitting ensures proper hose alignment and long-term performance.
