Product Description

This professional-grade central vacuum low voltage wire features 22 gauge, 2 conductor construction in a convenient 1000-foot box. The wire runs from vacuum inlets to the central vacuum unit and is used to turn the vacuum unit on by the switch in the handle of the central vacuum hose. Features double insulation jacket for added protection and durability.

Manufactured with 7-strand bare copper conductors for superior performance and reliability. The wire construction allows for easy installation through walls, basements, and attics. Can be run in series for multiple inlet connections. Professional installation grade suitable for residential and commercial applications.

Compatible with all major central vacuum brands including BEAM, Riccar, Lindhaus, Vacuflo, Intervac, Hide-A-Hose, and Chameleon systems. Meets industry standards for 24-volt, 20-gauge wire applications. Suitable for standard central vacuum installations requiring low voltage control wiring.

Available from Swiss Boy Vacuum, Utah's largest BEAM dealer and authorized dealer for premium central vacuum brands. Family-owned vacuum specialist serving the Wasatch Front since 1963 with expert installation and service. Contact our Bountiful, Utah location at 801-298-3656 for professional installation support.

Why Choose This Product?

• 22 AWG wire gauge with 2 conductor configuration
• Double insulation jacket provides enhanced wire protection
• 7-strand bare copper conductors maximize conductivity
• 1000-foot length handles large residential or commercial installations
• Series wiring capability supports multiple inlet connections
• 24-volt rating meets central vacuum system requirements
• Pull box packaging prevents wire tangles during installation
• Compatible with all major central vacuum brands and systems

Specifications

• Brand: Plastiflex
• Part Number: Not specified
• SKU: 7836395
• Wire Gauge: 22 AWG
• Conductors: 2 conductor
• Conductor Material: 7-strand bare copper
• Insulation: Double insulation jacket
• Length: 1000 feet
• Voltage Rating: 24 volt
• Package: Pull box
• Application: Central vacuum low voltage control

Compatibility

• BEAM: All SC and Serenity series models
• Riccar: R10, R20, R30 series central vacuum units
• Lindhaus: Centrino and Centro series systems
• Vacuflo: All residential and commercial models
• Intervac: All standard 24-volt systems
• Hide-A-Hose: All retractable hose systems
• Chameleon: All wall-mounted systems

Use Case

Essential for central vacuum installers and homeowners completing new installations or expanding existing systems. This wire connects wall inlets to the main vacuum unit, enabling automatic startup when the hose handle switch is activated. The 1000-foot length is ideal for whole-house installations, multiple inlet additions, or commercial applications requiring extensive low voltage wiring runs.
